ISOPAN: QUALITY GUARANTEE, CERTIFIED

Isopan SpA has always been com - mitted to product and service inno - vation and has been contributing for over forty years to the global challenge to improve the construc - tion sector with a view to environ - mental sustainability, with special emphasis being placed on improv - ing building performance, safety and energy efficiency. Isopan products help to obtain the prerequisites and credits need - ed for the most common building sustainability rating standards, such as LEED, BREEAM or Living Building Challenge.



CERTIFICATIONS

  • UNI EN ISO 9001:2015 Multisite Certification
  • CE Marking for panels both in Italy and in Europe pursuant to Directive 89/106/EEC
  • Adoption of standard EN
  • SGBC - Singapore Green Building Product

The new range of Isopan Sandwich Panels is FM Approved

Quality, technical integrity, and performance: the Isopan sandwich panel with PIR insulation joins the rock wool panel with FM Approvals certification.

FM APPROVALS certification for products with PIR insulation comes after the certification already obtained for sandwich panels in mineral wool. The safety guaranteed by the use of FM APPROVED products plays a key role in many sectors: from the world of Logistics to Cold Chain management and Oil&Gas.

Using FM APPROVED Isopan products will add greater value to your project thanks to the three pillars of FM: quality, technical integrity and performance.

FM Approvals is a testing and certification body that aims to prevent the loss of ownership of products and services for use in commercial and industrial facilities by verifying compliance with strict standards.

FM Approvals is part of FM Global, a global building insurance and risk management company.



Find out which Isopan panels are FM

In addition, for the German market

GENERAL CONSTRUCTION APPROVAL (ABG) AND GENERAL BUILDING SUPERVISORY APPROVAL (ABZ)

Isofire Roof
Isofire Wall
Isoparete plissè - Isoparete Evo - Isobox - Isofrigo - Isofrozen
Isocop - Isodeck PVsteel PU

CERTIFICATIONS' DETAILS
  • Without certificate
  • Certified producible
  • Certificate by extension
  • Performance released with Technical Note
Fire reaction
Fire reaction

FIRE REACTION CERTIFICATION: refers to the reaction of materials to the fire in the actual conditions of final application, with special focus on the degree of participation in the fire. Reaction to fire is a passive fire protection measure that carries out its main effects during the first propagation of the fire with the aim of limiting ignition of materials and propagation of the said fire (standard EN 13501-1)

Isopan panels limit ignition and propagation of flames in the event of a fire.

ATTENTION: The performances declared in the tables below, which are associated with different types of insulation, can vary based on the production of the building, in accordance with local and national regulations in force. Kindly check with Isopan. If not specifically requested, no performance will be provided.
Classification Isolation Category Product Thickness
A2 s1 d0 Isofire Roof
A2 s1 d0 Isofire Roof Fono
B s1 d0 Isodeck PVSteel MW
B s1 d0* Isocop
B s1 d0* Isotego
B s1 d0* Isotap
B s1 d0* Isodeck PVSteel PU
B s2 d0 Isocop
B s2 d0 Isotego
B s2 d0 Isodeck PVSteel PU
B s2 d0 Isodomus Classic
B s2 d0 Isocop Multifunzione
B s2 d0 Isotap
B s2 d0 Isovela
B s3 d0 Isocop
B s3 d1 Isocop
C s3 d0 Isocop
C s3 d0 Isotego
C s3 d0 Isotap
C s3 d0 Isodeck PVSteel PU
C s3 d0 Isodomus Classic
C s3 d0 Isocop Multifunzione
A2 s1 d0 Isofire Wall
A2 s1 d0 Isofire Wall Fono
A2 s1 d0 Isofire Wall Pliss
A2 s1 d0 Isoparete Fire Pliss
A2 s1 d0 Isoparete Fire Box
B s1 d0* Isofrigo
B s1 d0* Isofrozen
B s1 d0* Isobox
B s1 d0* Isobox Plisse
B s1 d0* Isopiano
B s1 d0* Isorighe
B s1 d0* Isoparete Plus 2
B s1 d0* Isoparete Pliss
B s1 d0* Isoparete Box
B s1 d0* Isoparete Piano
B s1 d0* Isoparete Evo
B s1 d0* Isoclass
B s2 d0 Isobox
B s2 d0 Isobox Plisse
B s2 d0 Isopiano
B s2 d0 Isorighe
B s2 d0 Isoparete Pliss
B s2 d0 Isoparete Box
B s2 d0 Isoparete Piano
B s2 d0 Isoparete Evo
B s2 d0 Isoparete Plus 2
B s2 d0 Isoclass
B s2 d0 Isofrigo
B s2 d0 Isofrozen
B s2 d0 Isofrigo G.I (giunto iniettato)
B s3 d0 Isobox
B s3 d0 Isobox Plisse
B s3 d0 Isopiano
B s3 d0 Isorighe
C s3 d0 Isobox
C s3 d0 Isobox Plisse
C s3 d0 Isopiano
C s3 d0 Isorighe
C s3 d0 Isoparete Plus 2
C s3 d0 Isoparete Pliss
C s3 d0 Isoparete Box
C s3 d0 Isoparete Piano
C s3 d0 Isofrigo
C s3 d0 Isofrozen
C s3 d0 Isoclass
Fire resistance
Fire resistance
FIRE RESISTANCE CERTIFICATION: refers to the load-bearing capacity and separating ability in case of fire for structural (e.g. walls, floors) and non-structural (e.g. doors, partitions) separation elements. Fire resistance is a fire protection measure to pursue in order to ensure an adequate level of safety of a building in case of fire (reference standard EN 13501-2.)

Isopan panels assure adequate fire resistance in case of fire.

ATTENTION: The performances declared in the tables below, which are associated with different types of insulation, can vary based on the production of the building, in accordance with local and national regulations in force. Kindly check with Isopan. If not specifically requested, no performance will be provided.
Classification Isolation Category Product Thickness
REI 120 Isofire Roof
REI 180* Isofire Roof
REI 240 Isofire Roof
REI 120 Isofire Roof Fono
REI 120* Isodeck PVSteel MW*
REI 60 Isofire Roof
REI 60 Isofire Roof Fono
REI 30 Isofire Roof
REI 30* Isocop
REI 15* Isodeck PVSteel *
REI 15* Isocop
EI 240 (wall) Isofire Roof
EI 60 (wall) Isofire Roof
EI 120* Isofire Wall
EI 120* Isofire Wall Fono
EI 30* Isofire Wall
EI 30* Isofire Wall Fono
EI 180 Isofire Wall
EI 180 Isofire Wall Fono
EI 90 Isofire Wall
EI 90 Isofire Wall Fono
EI 60 Isofire Wall
EI 60* Isofrozen*
EI 30* Isobox
EI 30* Isobox Plisse
EI 30* Isopiano
EI 30* Isorighe
EI 30* Isofrigo*
EI 30* Isofrozen*
EI 30* Isoparete Pliss
EI 30* Isoparete Box
EI 30* Isoparete Piano
EI 30* Isoparete Evo
EI30* Isoparete Fire Pliss
EI30* Isoparete Fire Box
EI 20* Isobox
EI 20* Isobox Plisse
EI 20* Isopiano
EI 20* Isorighe
EI 20* Isofrigo*
EI 20* Isoparete Pliss
EI 20* Isoparete Box
EI 20* Isoparete Piano
EI 20* Isoparete Evo
EI 15 Isofire Wall
EI 15 Isofire Wall Fono
EI 15* Isobox*
EI 15* Isobox Plisse*
EI 15* Isopiano*
EI 15 (ceiling) Isobox
EI 15 (ceiling) Isobox Plisse
EI 15 (ceiling) Isopiano
EI 15 (ceiling) Isorighe
EI 15 (ceiling) Isofire Wall
EW 240* Isofire Wall
EW 60* Isobox
EW 60* Isobox Plisse
EW 60* Isopiano
EW 60* Isorighe
Broof
Broof
B-ROOF CERTIFICATION: represents the specific assessment of external fire exposure to roofs and the fire reaction class of the installed photovoltaic module. The test methods and performance against fire are detailed in UNI CEN/TS 1187. The circular of the Fire Department accepts use of cover packages classified according to regulations such as B-roof (t2), B-roof (t3) and B-roof (t4). Identification of the test method used is indicated by (t1), (t2), (t3), and (t4), where the progressive number does not indicate more or less resistance to fire, but refers to the different test method. Performance is indicated by the letters: B-roof indicates maximum possible classification, whereas F-roof indicates no performance.

Isopan panels reduce the risk of fire spreading on roof coverings, thus making them suitable for installation of photovoltaic panels.

ATTENTION: The performances declared in the tables below, which are associated with different types of insulation, can vary based on the production of the building, in accordance with local and national regulations in force. Kindly check with Isopan. If not specifically requested, no performance will be provided.
BROOF Isolation Category Product Thickness
Broof(T2) Isodeck Pvsteel PU
Broof(T3) Isocop
Broof(T3) Isodomus Classic
Broof(T3) Isogrecata
Broof(T3) Isocop Multifunzione
Broof(T3) Isoray
Broof(T4) Isocop
Sound-insulation
Sound-insulation
SOUND INSULATION CERTIFICATION: represents the ability to isolate sound from one room to another. Laboratory measurements of airborne sound insulation is carried out according to EN ISO 140-3, UNI EN ISO 14140-2, UNI EN ISO 1793 Part 2 and 3 and UNI EN ISO 717-1

Isopan panels limit sound from one room to another.

ATTENTION: The performances declared in the tables below, which are associated with different types of insulation, can vary based on the production of the building, in accordance with local and national regulations in force. Kindly check with Isopan. If not specifically requested, no performance will be provided.
Performance Isolation Category Product Thickness
Rw=36dB Isofire Roof Fono
Rw=35dB Isofire Roof Fono
Rw=34dB Isofire Roof Fono
Rw=31dB Isofire Roof Fono
Rw=34dB Isodeck PVSteel FONO
Rw=34dB Isofire Roof
Rw=30dB Isofire Roof
Rw=29dB Isocop
Rw=24dB Isodomus Classic
Rw=35dB Isofire Wall Fono
Rw=34dB Isofire Wall Fono
Rw=34dB Isofire Wall
Rw=30dB Isofire Wall
Rw=29dB Isoparete Pliss
Rw=29dB Isoparete Box
Rw=29dB Isoparete Piano
Sound-absorption
Sound-absorption
SOUND ABSORPTION CERTIFICATION: represents the sound power portion, which, once it passes through the wall, it will no longer go back to the emitter environment and can take on a unit value as a maximum value. Measurement in a reverberation room of the sound absorption coefficient is carried out according to UNI EN ISO 354, UNI EN 1793-1 and UNI EN 1793-3.

Isopan panels are able to dampen sound reverberation, thus improving comfort in the area.

ATTENTION: The performances declared in the tables below, which are associated with different types of insulation, can vary based on the production of the building, in accordance with local and national regulations in force. Kindly check with Isopan. If not specifically requested, no performance will be provided.
Performance Isolation Category Product Thickness
w = 1 Isofire Roof Fono
w = 1 Isodeck PVSteel FONO
w = 1 Isofire wall Fono
